3G 4G GSM panel cross polarization antenna

 3G 4G Sigfox GSM panel cross polarization antenna

individual package MULMUTIBAND 4G PANEL antenna



Freqency Range:806-960/1710-2690MHz
Gain:8/10dBi
H-Beamwidth:65±10°
V-Beamwidth:65±10°
Polarization:±45°
F/B Ratio:≥20dB
Isolation:≥25dB
VSWR:≤1.5
Impedance:50Ω
2@33dBm:≤-107dBm
Max. Power:100W
Connector:2*N-K
Lightning Protection:DC grounding
