The IF060 interface module is a system module equipped with an insert slot for interface modules.
This makes it possible for any System 2005 CPU to use the IF060 to integrate various bus or network systems directly via the system bus.
The interface data must be prepared in the CPU. The IF060 module provides the physical connection to the insert modules.
Multiple IF060 interface modules can be inserted on the main backplane as required. The maximum number of IF060 modules that can be used depends on the type of interface module inserted, the transfer rate used and the performance of the CPU.
The following interface module inserts can be used with the IF060：
|
Module
|
Description
|
|
3IF613.9
|
Interface module with three RS232 interfaces
|
|
3IF621.9
|
Interface module with one RS485/RS422 interface and one CAN interface
|
|
3IF622.9
|
Interface module with one RS232 interface and two RS485/RS422 interfaces
|
|
3IF661.9
|
Interface module with one RS485 interface (Profibus DP slave)
|
|
3IF671.9
|
Interface module with one RS232 interface, one RS485/RS422 interface and one CAN interface
|
|
3IF672.9
|
Interface module with one RS232 interface and two CAN interfaces
|
|
3IF686.9
|
Interface module, 1 POWERLINK interface, managing or controlled node, electrically isolated
|
