2019 Brand new 3Ton Isuzu
600P NKR77 dump truck Tippers
Applications:
ISUZU 600P mini dump truck (also called Isuzu mini tipper truck, Isuzu sand dumper, Dump lorry truck, Cargo dumper trucks ) is designed
for both overseas and domestic high end heavy truck markets. In order
to prevail over its rivals in the global competition, key components of
the tipper truck are designed in close collaboration with top suppliers
in the world.
Powerstar ISUZU mini
dump truck is manufactured using the cutting-edge technology and
components in the world such as WABCO double-cylinder air compressor,
brake valve, HYVA front hydraulic system, etc.
Key Features:
---- ISUZU heavy duty chassis, perfect performance
---- ISUZU 4HK1-TCG40 engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Payloading from 2ton to 80 tons.
---- Easy operation and easy maintenance.
---- Virious types of tipper body are available.
Specifications:
|
ISUZU 4X2 6wheel dump tipper truck (3 tons)
|
|
General
|
Vehicle Brand
|
POWERSTAR
|
|
Chassis Brand
|
ISUZU NKR
|
|
Overall Dimension
|
5200 * 2200 * 2300 mm
|
|
GVW / Kerb Weight
|
7,300kg / 3,100kg
|
|
Cab
|
Cab Capacity
|
3 persons allowed
|
|
Air Conditioner
|
Heating/cooling air conditioner
|
|
Engine
|
Fuel Type
|
Diesel
|
|
Engine Brand
|
ISUZU 4HK1-TCG40
|
|
Power
|
120 HP (88KW)
|
|
Displacement
|
2999 ml
|
|
Emission Standard
|
Euro 3 or 4
|
|
Chassis
|
Drive Type
|
4X2, (left hand drive)
|
|
Transmission
|
5- speed levers with 1
reverse
|
|
Wheelbase/No. of axle
|
3360 mm / 2
|
|
Tire Specification
|
7.00-16
|
|
Tire Number
|
6 tires and 1 spare tire
|
|
Max Speed
|
95 km/h
|
|
Paint
|
Metallic paint
|
|
Superstructure
|
Pay loading capacity
|
3Tons
|
|
Cargo body
|
3500*2100*550
|
|
Thickness of cargo body
|
Bottom 5mm
Side 4mm
|
|
Cylinder type
|
T Type or Domestic 180 or HYVA 150
|
|
Lifting system
|
Middle or Front
|
|
Control
|
in the cabin
|
|
Color & LOGO
|
Accroding to wish
|
|
All standard accessories: All steel body with drop sides. Auto release removable trilgate.
Ladder, warning lights, PTO
fire extinguisher, basic tool kit, English manual……
|
|
Optional
|
** Back alarm and Camera can be equipped.
** Other tipper body can be choose.
** Other material and plate thickness can be choose.
|
---- SGS, BV, CONTECNA, CE Qualified.
---- Local engineer training support.
 |
|
 |
|
 |
| Special U-shape body |
|
Rear door safety hook |
|
Rear door top lug hooks |
 |
|
 |
|
 |
| Reinforced dumper body |
|
T-type hydraulic cylinder |
|
Mining body |
| |
|
|
|
|
---- 12 months FREE parts.
---- Factory genuine parts supply.
---- 7 days to worldwide by DHL.
| Operation Manual |
Chassis parts |
Maintenance Tools |
---- 15 years experiences Design & Export.
---- 100% customer made trucks.
---- Fast delivery assurance.
---- Service more than 60 countries.
---- Professional guidance on your importing documents.
---- CO, FORM E, FORM P, Pre-shipping Inspection...
---- Maximize save your sea freight.
---- Professional guidance on your importing documents.
---- Safety, Quickly, Timely
---- Quickly ship to worldwide.
---- Color and LOGO can be wished.
