Specification

Model name

TSM043WQZO-07P

Display type

4.3 inch tft, transmissive

Power supply

3.3v

Module current

40-60MA

Driver element

a-si TFT Active matrix

Outline Dimension(mm)

125.0x73.8x11.0

A.A.(mm)

95.04x53.86

Driver IC

SSD1963

Resolution

480x272 resolution

Viewing Direction

6H

Operating temperature(°C)

-20-70

Storage temperature(°C)

-30-80

Backlight

7 LEDs, white

Display mode

Normally white

Interface

8080 MCU, 8/16 bit

Touch screen

with RTP

Module lifetime(Hours)

50,000-100,000
