4 workers 2 hours 1unit flat pack container home
|
Install Time:
|
4 workers 2 hours
|
|
Wind resistance:
|
wind speed≤120 km/h
|
|
Earthquake resistance:
|
Grade 7
|
|
Snow load capacity of roofing:
|
0.6kn/m2
|
|
Live load capacity of roofing:
|
0.6kn/m2
|
|
Wall permitted loading:
|
0.6kn/m2
|
|
Heat conductivity coefficient:
|
0.35kcal/m2hc
|
|
Delivery time:
|
About 15-20 working days
|
|
Container loading:
|
8 sets/1*40HQ
|
Product Features
Product Details
It's flexible and customizable.
Get creative and enjoy the flexibility of flat pack modular house. These units can be stacked and arranged together according to your preference and design aesthetic.
This modular feature makes expansion easier and less costly. The house components like the doors, windows, and flooring can be custom selected too according to application.
It's sturdier and more durable.
detachable flat pack container house are redesigned with upgraded materials to withstand more load. The new and improved design is sturdier and more durable.
The EPS panel walls are thicker, metal upgraded from 0.276mm to 0.326mm, EPS density upgraded from 8kg to 10kg,and all the beams and purlin are rust-proof with galvanized steel bar sheets. The secondary beams and supports are structurally reconfigured.
|
size:
|
2250*5800*2800/2438*5800*2896mm
|
|
Steel structure :
|
bending steel plate
|
|
Wall:
|
50/75/100mm EPS sandwich panel /rock wool sandwich panel,0.326/0.376/0.426/0.476mm steel sheet
|
|
Wall color:
|
White color and optional colors
|
|
Roof:
|
50mm EPS sandwich panel /rock wool sandwich panel ,0.326/0.376/0.426/0.476mm steel sheet
|
|
Door :
|
50mm EPS sandwich panel /rock wool sandwich panel ,0.326/0.376/0.426/0.476mm steel sheet with lock /optional doors
|
|
Window :
|
Aluminum sliding door, PVC sliding door with security bar
|
|
Floor:
|
MGO board /optional floor
|
|
Decoration wall:
|
Optional : PVC cladding ,WPC cladding
|
|
Electricity:
|
Optional standard
|
Container house conversions produce up to 80% of our flat packages locally which allow us to used tried and tested material while promotion domestic and oversea market and controlling the quality of the units produced. Our flat pack container home are used, not exclusively, for the following:
-
Classrooms
-
Ablutions
-
Guard huts
-
Recreational facilities
-
Luxury office / Office complexes
-
Camps
-
Boardrooms
-
Kitchens
-
Restaurants / Mess halls
-
Accommodation units / Houses
-
Hospital / Clinics
