Feature:
650Hz speed loop response frequency
3 times overload capacity
Low noise and vibration
Very high cost-effective
Build in vibration suppression
Spec. table
|
Model
|
60ST-M01330A
|
|
Rated power
|
400w
|
|
Encoder
|
2500 ppr optical encoder
|
|
Rated line Voltage
|
220V
|
|
Rated line current
|
1.2A
|
|
Rated speed
|
3000rpm
|
|
Rated torque
|
1.3Nm
|
|
Peak torque
|
1.91Nm
|
|
BEMF
|
30.9 V/1000rpm
|
|
Torque constant
|
0.53Nm/A
|
|
Rotor inertia
|
0.175 X10^-4 kg.m^2
|
|
Winding resistor
|
6.18 ohm
|
|
Winding inductance
|
29.3mH
|
|
Electric constant
|
4.74 ms
|
|
Weight
|
1.16kg
|
|
Protection grade
|
IP64
|
|
Insulation grade
|
Class F
|
|
Brake
|
Optional
|
