472059A ESMC FLEXI EDGE 36 TRX SYSTEM MODULE Base Station Overview
Place of Origin: Guangdong, China
Brand Name: Nokia
Model Number: ESMC
Product Code: 472059A
Product Series: Wireless
Discription:
|
ESMC
|
472059A
|
472059A.101/ 472059A.102
|
Flexi Multiradio System Module(36TRX) Base Station
|
ESMC has an integrated transport unit, it provides the transfer function of physical transmission interface and base station. Provides 6 different network interface: E1 symmetrical,,E1 unsymmetrical,T1,Fast Ethernet, Gigabit Ethernet and Flexbus. The transmission interface with the Flexi EDGE System Module ESMA.
ESMB/ESMC has 12 integrated alarm input and 6 output control, external alarm input number with Flexi external alarm extension unit (FSEB) can be increased to 24. The wireless module to the remote and distributed base station provides external alarm and control interface application. The RRH module has 2 alarm input, 4 alarm input RFM and 4 control output to make it compatible with the system alarm module interface.
Specification
-
18 frequency baseband processing capacity.
-
O&M, Abis distribution, transmission, synchronization.
-
With Flexi GSM BTS universal transmission plate.
-
Through OBSAI (optical RP3 01) fiber interface module (RRU).
-
Provide 4 * (optical RP3 01) optical fiber interface.
-
IP 65 degree of protection, all-weather outdoor installation.
-
Working temperature: -35~+55 degrees Celsius.
