Technical Specifications
|
General
|
|
Dimension
|
127x60x38mm
|
|
Weight
|
270G
|
|
Operating Voltage
|
DC7.4~8.4V
|
|
Frequency Band
|
|
GSM
|
EGSM900MHz
|
|
DCS1800MHz
|
|
CDMA2000/EVDO
|
BC0
|
|
WCDMA
|
BAND1
|
|
BAND8
|
|
TD-SCDMA
|
TD-SCDMA 1.9G
|
|
TD-SCDMA 2G
|
|
LTE-FDD
|
LTE-FDD B1
|
|
LTE-FDD B3
|
|
LTE-FDD B8
|
|
LTE-TDD
|
LTE TDD B38
|
|
LTE TDD B39
|
|
LTE TDD B40
|
|
LTE TDD B41
|
|
TX Power
|
|
GSM/GPRS Power Level
|
EGSM900: 4 (2W)
|
|
DCS1800: 1 (1W)
|
|
EDGE Power Level
|
DGSM900: E2 (0.5W)
|
|
DCS1800: E1 (0.4W)
|
|
CDMA 1X Power Level
|
3 (0.25W)
|
|
UMTS Power Level
|
WCDMA: 3 (0.25W)
|
|
EVDO: 3 (0.25W)
|
|
TD-SCDMA: 2 (0.25W)
|
|
LTE Power Level
|
3 (0.25W)
|
|
Receiving Sensitivity
|
|
Frequency
|
Sensitivity
|
Sensitivity(Max)
|
|
EGSM900
|
＜-109dBm
|
3GPP
|
|
DCS1800
|
＜-109dBm
|
3GPP
|
|
WCDMA 2100
|
＜-110dBm
|
3GPP
|
|
WCDMA 900
|
＜-109dBm
|
3GPP
|
|
TDSCDMA 1900
|
＜-109dBm
|
3GPP
|
|
TDSCDMA 2000
|
＜-109dBm
|
3GPP
|
|
CDMA BC0
|
＜-109dBm
|
3GPP
|
|
LTE FDD/TDD
|
As follows
|
3GPP
|
|
Reference sensitivity
|
|
E-UTRA
|
3GPP Standard
|
Test Data
|
3GPP Standard
|
Duplex Mode
|
|
Frequency Band
|
1.4MHz
|
3MHz
|
5MHz
|
10MHz
|
10MHz
|
15MHz
|
20MHz
|
|
1
|
-
|
-
|
-100
|
-97
|
-101
|
-95.2
|
-94
|
FDD
|
|
3
|
-101.7
|
-98.7
|
-97
|
-94
|
-99
|
-92.2
|
-91
|
FDD
|
|
8
|
-102.2
|
-99.2
|
-97
|
-94
|
-102
|
|
|
FDD
|
|
38
|
-
|
-
|
-100
|
-97
|
-101
|
-95.2
|
-94
|
TDD
|
|
39
|
-
|
-
|
-100
|
-97
|
-101.5
|
-95.2
|
-94
|
TDD
|
|
40
|
-
|
-
|
-100
|
-97
|
-101
|
-95.2
|
-94
|
TDD
|
|
41
|
-
|
-
|
-99
|
-96
|
-101
|
-94.2
|
-93
|
TDD
|
|
GPS Parameters
|
|
GPS Sensitivity
|
-159 dBm (GPS) / -158dBm (GLONASS) / TBD (BD)
|
|
Cold Start Sensitivity
|
-148 dBm
|
|
Positioning Accuracy (in the open air)
|
2.5m (CEP50)
|
|
TTFF（In the open air）
|
Hot Start＜1S，Cold Start＜35S
|
|
Type
|
16-channel, C/A Code
|
|
GPS L1 Frequency
|
1575.42±1.023MHz
|
|
GLONASS Frequency
|
1597.5~1605.8MHz
|
|
BeiDou Frequency
|
1559.05~1563.14MHz
|
|
Update Frequency
|
Default 1 Hz
|
|
GNSS Data Format
|
NMEA-0183
|
|
GNSS Current Consumption
|
100mA (GSM/CDMA 1X/UMTS/LTE 休眠，VBAT引脚)
|
|
GNSS
|
Active
|
