Pagoda tent structures provide the means to create eye-catching tensile roof structures.
Together with ease of assembly and perfect build-quality, the pagoda tent series provide the perfect solution for a vast range of applications.
Pagoda tent structures are available in a variety of square sided units from 3m through to 10m in clear span width.
|
Model
|
Size(m)
|
Eave height(m)
|
RIdge height(m)
|
Main profile size(mm)
|
|
PGA03
|
3x3
|
2.5
|
4.3
|
65x65x2.5
|
|
PGA04
|
4x4
|
2.5
|
4.8
|
65x65x2.5
|
|
PGA05
|
5x5
|
2.5
|
5.4
|
65x65x2.5
|
|
PGA06
|
6x6
|
2.5
|
5.9
|
65x65x2.5
|
|
PGA08
|
8x8
|
2.6
|
6.0
|
122x68x3
|
|
PGA10
|
10x10
|
2.6
|
6.5
|
122x68x3
|
Pagodas create an ideal solution for reception areas or can be joined together by the use of integrated gutters,which enables the formation of multiple configurations enhancing the visual impact of any event whatever the location.
System Features(3m to 6m square pagoda tent)
1.Hard pressed extruded aluminum frame with 3 channels, 65x65x2.5mm
2.Elegant high peak tensile roof
3.Easy assemble and dismantle
4.Internal galvanized steel insert for eave connection
5.Single unit can be joined together to make a larger space by integrated gutters
6.Full accessories available such as linings,flooring,clear windows,hard wall system etc.
