50WW350 Non Oriented Electrical Silicon Steel
Non-oriented Electrical steel CRNGO fully processed steels are iron-silicon alloys with varying silicon contents and have similar magnetic properties in all directions in plan of the sheet. Non-oriented Electrical steel are principally used for motors, generators, alternators, relays, armatures, and solenoids, ballasts, small Transformers and a variety of other electromagnetic applications.
50WW350 Non Oriented Electrical Silicon Steel Plate/Coil/Strip
WanJuan Steel is manufactured to exhibit excellent magnetic properties in one direction (the rolling direction) of a steel sheet. We offer Non-grain-oriented electrical steel sheet/coil/strip with excellent magnetic flux density and iron loss characteristics.
Quick Info
- Type:Non-oriented Silicon Steel
- Thickness:0.35 - 0.5 mm
- Tolerance:1%
- Standard:GB
- Technics:Tape Winding
- Technique:Cold Rolled
Specification
|
Brand Name |
Nominal Thickness (mm) |
Theoretical Density kg/dm3 |
Max Iron Loss
W/kg |
Min Magnetic InductionT B5000 |
Min Number of Bends |
Min Stacking Factor % |
|
35WW230 |
0.35 |
7.60 |
2.30 |
1.62 |
2 |
95.0 |
|
35WW250 |
7.60 |
2.50 |
1.62 |
2 |
||
|
35WW270 |
7.65 |
2.70 |
1.62 |
2 |
||
|
35WW300 |
7.65 |
3.00 |
1.62 |
5 |
||
|
35WW360 |
7.65 |
3.60 |
1.63 |
5 |
||
|
35WW400 |
7.65 |
4.00 |
1.63 |
5 |
||
|
35WW440 |
7.70 |
4.40 |
1.65 |
5 |
||
|
50WW230 |
0.50 |
7.60 |
2.30 |
1.62 |
2 |
97.0 |
|
50WW250 |
7.60 |
2.50 |
1.62 |
2 |
||
|
50WW270 |
7.60 |
2.70 |
1.62 |
2 |
||
|
50WW290 |
7.60 |
2.90 |
1.62 |
3 |
||
|
50WW310 |
7.65 |
3.10 |
1.62 |
5 |
||
|
50WW350 |
7.65 |
3.50 |
1.62 |
5 |
||
|
50WW400 |
7.65 |
4.00 |
1.63 |
10 |
||
|
50WW470 |
7.70 |
4.70 |
1.64 |
10 |
||
|
50WW600 |
7.75 |
6.00 |
1.66 |
10 |
||
|
50WW700 |
7.80 |
7.00 |
1.67 |
10 |
||
|
50WW800 |
7.80 |
8.00 |
1.68 |
10 |
||
|
50WW1000 |
7.85 |
10.00 |
1.70 |
10 |
||
|
50WW1300 |
7.85 |
13.00 |
1.72 |
10 |
