INTRODUCTION
Features:
1, It has strong overload capability and can drive single phase AC water pump with 1:1 horse power;
2, MPPT technology,efficiency >99%,wide range of MPPT input voltage ranges;
3, Adopt advanced IPM power module;
4, IP65 and fanless design,aluminium casting,outdoor use, adapt to harsh application environments;
5, Operating Temperature:-25~60℃;＞60℃ need derate operating;
6, Perfect system protection, like undervoltage, overload, overvoltage,overcurrent, well dry, phase loss, short circuit,overheating, etc.
7, Solar to motor with isolation design,more safty;
|
Model
|
JNP370L
|
JNP370LS
|
JNP550L
|
JNP550LS
|
|
PV Input
|
|
D.C. Max. Input Voltage
|
110V
|
160V
|
|
Recommended MPPT Voltage
|
55~110V
|
80~160V
|
|
D.C. Max. Input Current
|
12A
|
10A
|
|
Max. MPPT Efficiency
|
>99%
|
|
Number of String
|
1
|
|
A.C. Output
|
|
Max. Motor Output Power
|
370W
|
550W
|
|
Rated Output Voltage
|
220/230Vac (3PH)
|
220/230Vac(1PH )
|
220/230Vac (3PH)
|
220/230Vac(1PH )
|
|
Output Frequency Range
|
0~50/60Hz
|
|
Rated Output Current
|
2A
|
3A
|
|
System
|
|
Protection level
|
IP65
|
|
Operating Temperature
|
-25~60℃
|
|
Cooling Way
|
自然冷却
|
|
Display
|
LED灯
|
|
Altitude
|
3000米, 3000米以上降额运行
|
|
Noise Emission
|
<45dB
|
|
Compliance
|
EN 50178; IEC/EN 62109-1
|
|
Dimension（W/H/D）
|
200/300/80(mm)
|
|
Weight
|
3.4kg
|
