Features:
1. This 55KW solar pump inverter has strong overload capability and can drive the 3ph pump with 1:1 horse power;
2. Advanced dynamic MPPT function, efficiency >99%;wide range of MPPT input voltage ranges;
3, Adopt advanced IGBT power module;
4. Aluminum case,IP65 design,speed regulating heat dissipation,outdoor use, adapt to harsh application environments;
5. RS485 and GPRS remote monitoring and start-stop management through APP;
6. Meet the simultaneous input of the utility Grid/DG and solar, automatic switching, online energy complementary, solar priority, keep the pump rated work, and achieve 24H water supply.
7 .Perfect system protection, undervoltage, overload, overvoltage, overcurrent, grid phase loss, pump dry, phase loss, short circuit, overheating, etc.
8. Fully automatic operation control, soft start and soft stop,one key to start.
|
Max. Input DC voltage
|
880Vdc
|
|
Recommended MPPT voltage
|
460-850Vdc
|
|
Max. Input DC current
|
100A
|
|
Max. MPTT efficiency
|
99%
|
|
Number of Strings
|
1
|
|
Max. applicable motor output power
|
45KW
|
|
Rated output voltage
|
380-460Vac 3 phase
|
|
Output frequency range
|
0-50/60Hz
|
|
Rated output current
|
86A
|
|
Dimension(W/H/D)
|
460x580x251mm
|
|
weight
|
32.5kg
|
|
Max. efficiency
|
98%
|
|
Protective class
|
I
|
|
Protection degree
|
IP65
|
|
Environment temperature
|
-25ºC-+60ºC above 60ºC need derate operation
|
|
Cooling method
|
Force cooling
|
|
Display
|
LCD
|
|
Communication interface
|
RS485
|
|
Altitude
|
3000m; above 3000m need derate operating
|
|
Noise emission
|
<50dB
|
|
compliance
|
EN 50178; IEC/EN 62109-1; IEC61800
|
