1 PLC intelligent control equipment,
has a continuous convex point easily eliminate clearance
2 Use hot air circulation heating mode, high thermal efficiency
3 Coating method : continuous and intermittent coating
3.1 The first face automatic fixed-length block coating
3.2 The second face automatic tracking the first face composite
coating
3.3 Reverse coating interval length distance
4 Coating length : More than 50mm can set clearance or continuous
coating
The minimum coating length : 8mm, Minimum interval length : 5mm,
The minimum track length : 50mm
5 Double-sided dry thickness accuracy : ≤±0.003mm
5.1 Both the front and coated alignment error : ≤±0.5mm
5.2 Each length error : ≤±0.5mm
5.3 Each paragraph width error : ≤±0.5mm
5.4 Trailing : ≤±0.5mm
6 Volume release tension can be adjusted continuously : 0～25N
7 Precision rectification controller : ±0.2mm(Re)
8 Core winding diameter : 3 inches, USES the gas rose axis,
Max 300kg
9 Baking mode :
9.1 Hot wind drying, hot wind circulation,
9.2 Electric heating,
9.3 Hot air volume can be adjusted, air volume can be adjusted
10 Oven material :
Both inside and outside is made of stainless steel,
oven shell thickness is 1.5 mm
11 Oven temperature: RT- 150 ℃,
each segment can be independently adjustable,
temperature control precision＜±1℃.
12 Coating roll diameter : Φ120 mm
13 Max winding diameter : Φ500 mm,Max volume weight 300 kg
|
