Dimension(Lx W xH)unloaded
|
6295×2500×3260
|
Approaching angle/Departure angle°
|
26/35
|
Overhang(front/rear) (mm)
|
1410/1085
|
Wheel base (mm)
|
3800
|
Max speed km/h
|
90
|
Curb weight kg
|
7320
|
Max Towing Weight kg
|
34800
|
Max slope climbing %
|
30
|
Max loading on fifth wheel, Permitted(kg)
|
10500
|
Engine
Steyr technology, made in China
|
Model
|
WP10.336,water-cooled,four strokes,6 cylinders in line,turbocharged, directly injection
|
Displacement L
|
9.726/Diesel
|
Bore X stroke (mm)
|
126/130
|
Max power kw/rpm
|
235/2200
|
Max torque Nm/rpm
|
1250/1400-1600
|
Emission
|
EURO3
|
Fuel tanker L
|
400
|
Clutch
|
Model
|
GFX420, Single dry frictional disc,Hydraulic control and compressed air assisted
|
Gearbox
|
Model
|
RT11509C mechanism,9gears,1reverse gear, manual, synchronization
|
Brake system
|
Service brake
|
Brake gap can be adjusted automatically, double circulation air brake system
|
Assistant brake
|
Engine exhaust brake
|
Park brake
|
Potential springs pressing on middle and rear wheels
|
Steering system (ZF company)
|
Model
|
ZF 8098,whole circulation in ball, hydraulic booster
|
Frame
|
Fish belly, shape, variable width, variable sections, side beam structure
|
The fifth wheel
|
Model
|
50#Single
|
Height of fifth wheel(mm) (unload)
|
1410
|
Radius of front gap (mm)
|
2300
|
Radius of rear slew (mm)
|
1720
|
Front axle (Mercedes Benz Technology)
|
Double-shoe pneumatic brake, non-driving steering axle
|
Middle and Rear axle (Mercedes Benz Technology)
|
Double-shoe pneumatic brake, casting, double reduction driving axle
|
Tyre
|
12.00-R20
|
Electrical system
|
Battery
|
2X12V/135Ah
|
Generator
|
28V-35A
|
Starter
|
5.4Kw/24V
|
Cab
|
Long cab with single sleeper;
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
With air suspension seat for driver
|
