7 years warranty 24v 96w triac dimmable constant voltage led driver with CE UL ROHS

A series of 96w triac dimmable led driver divide triac dimmable constant voltage led driver & triac dimmable constant current led driver. Through 100% full load burn-in test. It application with indoor & outdoor illuminating lights.




  • CertificationUL CE ROHS
  • Size230*70*46mm
  • Dimming modeTriac Dimmable
  • Working Modeconstant voltage
  • Output Current96w
  • Output Voltage24v
  • Input Voltage100~277VAC

7 years warranty 24v 96w triac dimmable constant voltage led driver with CE UL ROHS


LED power supply 24v 96w is a model of triac dimmable constant voltage led driver,the Efficiency > 82% / Dimming range: 0~100% .we give 7 years warranty. it is IP67 design for indoor or outdoor installations


 Specification

model

SMT-024-096VTHW

Output

DC Voltage

24V



Voltage Accuracy

±0.5V



Rated current

4.0A



Rated power

96W

Input

Voltage Range

100~277V AC



Frequency Range

4763HZ



Power Factor ( Typ.

PF≧0.95/110V,PF≧0.97/277V



Full Load Efficiency(Typ.)

>82%



AC CurrentTyp.

1.33A/110VAC



Inrush Current Typ.

20A, 50%, 1.6ms



Leakage current

0.5mA/110V

Protection

Short Circuit

Hiccup mode, recovers automatically after fault condition

is removed.



Over temperature

100℃±10℃ shut down o/p voltage, automatically recover after cooling.





Over Loading

≤120% constant current limiting, auto-recovery



Over voltage

140VAC(90~135V) , ≦270VAC(170~265V)

Environment

Working TEMP.

-40+60℃



Working Humidity

2090%RH,non-condensing



Storage TEM.,Humidity

-40+80℃1095%RH



TEMP.coefficient

±0.03%/℃050℃



Vibration

10500Hz2G 10min./1 cycleperiod for 60min.

each along X,Y,Z  axes

Safety&EMC

Safety standards

UL8750+UL1310



Withstand voltage

I/P-O/P:3.75KVAC



Isolation resistance

I/P-O/P100MΩ/500VDC/25℃/70%RH



EMC EMISSION

FCC Part 15 B



EMC IMMUNITY

Compliance to EN55015; EN61000-4-2,3,4,5,6,8,11,EN61547

Alight industry level surge4KV

Others

Net Weight

1.1Kg



Size

230*70*46mmL*W*H)



packing

329*279*176mm , 10PCS/ctn

Notes

1.  All parameters NOT specially mentioned are measured at 110V/277VAC input , rated load and

25℃of ambient temperature.

2.  Tolerance:includes set us tolerance,line regulation and load regulation



Triac dimmable led driver
dali led power supply
0-10v led driver
slim size led driver



Triac dimmable led driver 96w


 Application

All of our drivers are got UL CE FCC ROHS listed .OEM Welcome.
Our led drivers are widely used for:
  • 1.Indoor LED illuminating lights
  • 2.LED Neon, LED urban Decoration
  • 3.LED Lighting Advertising,LED Display
  • 4.Safety Protection Apparatus
  • 5.Telecommunications, Networks
  • 6.Vehicle Lights, Controller Panels
