A quality built snow blower that really works!
- Throw snow up to 40' while clearing paths down to the ground.
- Features a no freeze-up chute design!
- Two important factors must be considered when purchasing a snowblower for your skid steer loader – gallons per minute and hydraulic pressure (psi) are very important to the ultimate performance and your satisfaction.
- Discuss these factors with your product specialist when purchasing.
Features
- Direct-drive hydraulic auger
- Replaceable bolt-on high-carbon steel cutting edge
- Hydraulic relief - no shear pins
- Hydraulic control valve with electric solenoid controls all chute functions with built-in pressure relief system eliminating the need for shear pins.
- Easily adjustable depth skid shoes
- Throws snow up to 40'
|
Cutting Width
|
72" - 1830mm
|
|
Cutting Height
|
26" - 660mm
|
|
Auger Diameter
|
13" - 330mm
|
|
Fan Diameter
|
20" - 508mm x 5pcs
|
|
Chute Rotation
|
Hydraulic 270°
|
|
Spout Diameter
|
9.5" - 240mm
|
|
Weight
|
417kg
|
|
Hydraulic Flow
|
15-23GPM
|
|
Operating Pressure
|
2500-3500PSI (17-24Mpa)
|
