Specification
LIGHT SOURCE
Lamp: Philips 230W
CT: 8000 K
Lifespan: 2,000H
OPTICS
High precision glass optic system
COLORS
1 Color wheel: 13 color+open
Half-color effect, linear color change, bidirectional rotating
rainbow effect
GOBOS
1 Static gobo wheel：14 gobos+open, shakable and
bi-directionally rotatable at variable speeds
MOVEMENT
Pan movement: limitless(16 bit )
Tilt movement: 240°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth
FEATURES
Prism: 8-facet, bi-directionally rotatable at
variable speeds
Strobe: mechanical shutter , variable from
1-20Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable
High speed shaking effect
DISPLAY
2.4 inch full color LCD display, show
customer logo
15 second standby auto lock
SOFTWARE
Control mode: DMX512, master-slave,
auto-run, sound activate
Channel: 8CH
Run
time of lamp and fixture record
OTHER SPEC
Fixture and lamp usage time display
Built-in analyzer for easy fault finding,
error messages
Input signal isolating protection
Auto thermal protection circuit
Housing: high temperature UV resistant ABS
POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 300W@220V
DIMENSIONS AND WEIGHT
Fixture dimension: 28*25*50cm
Packing dimension:
36x32x54cm(Carton)
60x30x56cm(2 in 1 flightcase)
60x55x56cm(4 in1 flightcase)
Net Weight: 7.5kg
Gross Weight:
9.5kg(Carton)
28kg(2 in 1 flightcase)
50kg(4 in 1 flightcase)
