Terminal Name Description Related
Parameter (4)
–10V –10V reference Negative 10V DC for analog inputs. 2 kΩ min
10VC 10V common For (–) and (+) 10V references.
+10V +10V reference Positive 10V DC for analog inputs. 2 kΩ min
Sh Shield Terminating point for wire shields when an
EMC plate or conduit box is not installed.
Ao0– Analog out 0 (–) Bipolar, ±10V, 11 bit and sign, 2 kΩ min
load.
4…20 mA, 11 bit and sign, 400 Ω max load.
