Weight
|
1.115kg
|
|
Dimensions
|
133×126×130mm
(D×W×H)
|
|
Printing method
|
Direct thermal
|
|
Print width
|
72mm
|
|
Column capacity
|
576
dots/line 512 dots/line
|
|
Printing speed
|
300
mm/s
|
|
Interface
|
USB+Serial，USB+Lan，USB+Serial+BT,
USB+Serial+WIFI
|
|
Printing paper
|
79.5±0.5mm
|
|
paper width
|
82.5mm/80mm/58mm
|
|
Line spacing
|
3.75mm (Adjustable by commands)
|
|
Column number
|
80mm
paper: Font A - 42 columns or 48 columns/Font B - 56 columns or 64
columns/
|
|
Chinese,traditional Chinese - 21 columns
or 24 columns
|
|
Character size
|
ANK，Font
A：1.5×3.0mm（12×24 dots） Font B：1.1×2.1mm（9×17 dots）
Chinese,traditional Chinese:3.0×3.0mm（24×24 dots）
|
|
Cutter
|
Auto cutter
|
|
Barcode Character
|
|
Extension character
|
PC347（Standard
Europe）、Katakana、PC850（Multilingual）、PC860（Portuguese）、PC863（Canadian-French）、PC865（Nordic）、West
Europe、Greek、Hebrew、East
Europe、Iran、WPC1252、PC866（Cyrillic#2）、PC852（Latin2）、PC858、IranII、Latvian、Arabic、PT151（1251）
|
|
sheet
|
|
Barcode types
|
UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128
|
|
2D code
|
QR
CODE / PDF417
|
|
Input buffer
|
64k
bytes
|
|
NV Flash
|
256k
bytes
|
|
Power
|
|
|
Power adaptor
|
Input：AC
110V/220V, 50～60Hz
|
|
Power source
|
Output：DC
24V/2.5A
|
|
Cash drawer output
|
DC
24V/1A
|
|
Physical characteristics
|
|
|
Weight
|
1.115
KG
|
|
Dimensions
|
133×126×130mm
(D×W×H)
|
|
Environmental Requirements
|
|
|
Work environment
|
Temperature (0～45) humidity(10～80%)
|
|
Storage environment
|
Temperature(-10～60℃)
humidity(10～80%)
|
|
Reliability
|
|
|
Cutter life
|
1.5
million cuts
|
|
Printer head life
|
100KM
|
