Overview
Brand: COMMSCOPE
Part Number: 8460714/10 5EN5-I GRAY CPK
Discription: 5EN5-i Category 5e U/UTP Cable, non-plenum CM rated, gray jacket, 4 pair count, 1000 ft (305 m) length, CommPak
Specification
|
Construction Materials
|
|
Jacket Material
|
PVC
|
|
Conductor Material
|
Bare copper
|
|
Insulation Material
|
Polyolefin
|
|
|
Dimensions
|
|
Cable Length
|
305 m | 1000 ft
|
|
Cable Weight
|
19.48 lb/kft
|
|
Diameter Over Jacket, nominal
|
4.877 mm | 0.192 in
|
|
Jacket Thickness
|
0.432 mm | 0.017 in
|
|
|
Electrical Specifications
|
|
ANSI/TIA Category
|
5e
|
|
Characteristic Impedance
|
100 ohm
|
|
dc Resistance Unbalance, maximum
|
5 %
|
|
dc Resistance, maximum
|
9.38 ohms/100 m
|
|
Delay Skew, maximum
|
15 ns
|
|
Mutual Capacitance
|
5.6 nF/100 m @ 1 kHz
|
|
Nominal Velocity of Propagation (NVP)
|
69 %
|
|
Operating Frequency, maximum
|
200 MHz
|
|
Operating Voltage, maximum
|
80 V
|
|
Transmission Standards
|
ANSI/TIA-568-C.2 | CENELEC EN 50288-3-1 | ISO/IEC 11801 Class D
|
|
Dielectric Strength, minimum
|
1500 Vac | 2500 Vdc
|
|
Note
|
All electrical transmission tests include swept frequency measurements
|
|
|
Environmental Specifications
|
|
Environmental Space
|
Non-plenum
|
|
Flame Test Method
|
CM
|
|
Installation Temperature
|
0 °C to +60 °C (+32 °F to +140 °F)
|
|
Operating Temperature
|
-20 °C to +60 °C (-4 °F to +140 °F)
|
|
|
General Specifications
|
|
Cable Type
|
U/UTP (unshielded)
|
|
Packaging Type
|
|
|
Pairs, quantity
|
4
|
|
Cable Component Type
|
Horizontal
|
|
Jacket Color
|
Gray
|
|
Product Number
|
5EN5-i
|
|
Conductor Gauge, singles
|
24 AWG
|
|
Conductor Type, singles
|
Solid
|
|
Conductors, quantity
|
8
|
|
Ordering Note
|
Available in Asia Pacific
|
|
|
Mechanical Specifications
|
|
Pulling Tension, maximum
|
11 kg | 25 lb
|
