Description
SIF-EX high temp silica fabric is made by minimum 96% SiO₂ silicon dioxide content, continuous resistant 1000 degree C. It is used to industry heat protection.
Features
Available with PSA adhesive backed.
Application
It is used for equipment protection, welding curtains and blankets.
Specifications
|
DATASHEET
|
|
Part NO.
|
Weight
|
Thickness
|
Width
|
Wrap
|
Weft
|
Tensile strength(N/INCH)
|
|
g/m2
|
mm
|
cm
|
yarns/cm
|
yarns/cm
|
Wrap
|
Weft
|
|
SIF-XT-300
|
300
|
0.35
|
92
|
18.5
|
12.5
|
＞300
|
＞250
|
|
SIF-XT-500
|
500
|
0.60
|
92
|
18
|
13
|
＞500
|
＞400
|
|
SIF-XT-600
|
600
|
0.70
|
92/100
|
18
|
13
|
＞600
|
＞500
|
|
SIF-XT-880
|
880
|
1.00
|
92
|
18
|
13
|
＞800
|
＞600
|
|
SIF-XT-1150
|
1150
|
1.30
|
92/100
|
18
|
13
|
＞1000
|
＞750
|
|
SIF-XT-650
|
650
|
0.70
|
84
|
18
|
13
|
＞500
|
＞400
|
|
SIF-XT-1250
|
1250
|
1.30
|
84
|
18
|
13
|
＞760
|
＞600
|
|
Technical Datasheet
|
|
Material
|
Silica
|
|
Working temperature
|
-40℃ - +1000℃
|
|
Flammability
|
VW-1
|
|
Melting point
|
+1650℃
|
|
Standard Color
|
Nature
|
|
MOQ
|
100 meter each size
|
|
Cutting tool
|
Scissors
|
Notes:
Special thickness upon request
Special length or packing upon request.
