The analog I/O modules (with HART communication function) communicate with field devices and store analog data
and HART variables in the Input/Output image area in the communication module.
An FCS refers to and sets the
Input/Output image by accessing the analog I/O modules (with HART communication function). The FCS utilizes the
field device data via I/O terminals of the function block in the same way as other analog/digital I/O signals.
|
|
|
Model
|
|
AAI143
|
|
|
|
|
|
|
|
|
|
Number of input channels
|
|
16, isolated
|
|
|
|
|
|
|
|
|
|
Input signal
|
|
4 to 20 mA
|
|
|
|
|
|
|
|
|
|
Allowable input current
|
|
24 mA
|
|
|
|
|
|
|
|
|
|
Withstanding voltage
|
|
Between input and system: 1500 V AC, for 1 minute
|
|
|
|
|
|
|
|
Input resistance
|
|
Power ON
|
|
270 Ω (20 mA) to 350 Ω (4 mA)
|
|
|
Power OFF
|
|
500 kΩ or larger
|
|
|
|
|
|
|
|
|
|
Accuracy
|
|
±16 µA
|
|
|
|
|
|
|
|
|
|
Data update period
|
|
10 ms
|
|
|
|
|
|
|
|
|
|
Transmitter power supply
|
|
19.0 V or higher (at 20 mA) 25.5 V or less (at 0 mA) (output current limit: 25 mA)
|
|
|
|
|
|
|
|
|
|
Maximum current consumption
|
|
230 mA (5 V DC), 540 mA (24 V DC)
|
|
|
|
|
|
|
|
|
|
Weight
|
|
0.3 kg
|
YOKOGAWA AAI143-H00 S1
AAI143-H00 S1 | YOKOGAWA | Analog Input Module
Email:sales3@amikon.cn
1)100% full New! - Original Factory Seal !
2)Warranty: 12 months!
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3 days after payment
5)ship to you via DHL/TNT/UPS/EMS/Fedex.
6) All the goods will be tested before shipment
