Overview
The 1336-BDB-SP4D is an Allen-Bradley Adjustable frequency Gate Drive Board that is engineered under the 1336 series. The gate drive has a voltage of 460 Volts AC and it produces 20 Horsepower. Each of the modules effectively fits on frame sizes A, B, C, D, or E. The board also functions as a spare part for the adjustable frequency AC Drives classified under the 1336 PLUS, PLUS II, FORCE, IMPACT, and the REGEN series. The adjustable 1336-BDB-SP4D operates with AC drives that are normally rated between 3 and 800 Horsepower. The 1336-BDB-SP4D uses the DC Bus (Frame B and UP) input inductor and the Logic ride-through for the 1336-BDB-SP4D ranges between 0.5 seconds minimum and 2 seconds maximum. The drive comes with a transient protection of MOV supporting up to 6000 Volts Peak per IEEE. It also includes optional DC input terminals. The output power or the carrier frequency for the 1336-BDB-SP4D is 2 to 12 Kilo Hertz and has an output frequency range of 0 to 400 Hertz. The efficiency rating for the 1336-BDB-SP4D is 97.5% at the rated Amps or nominal line Volts. The overload capability for the 1336-BDB-SP4D rates 150% for 60 seconds while in heavy-duty mode.
