Overview
Option L5/L5E & L8E - 24V AC/DC Interface Board Requirements
Circuits used with these options must be capable of operating with
high = true logic.
DC external circuits in the low state must generate a voltage of no
more than 8V
DC. Leakage current must be less than 1.5 mA into a
2.5k ohm load.
AC external circuits in the low state must generate a voltage of no
more than 10V
AC. Leakage current must be less than 2.5 mA into a
2.5k ohm load.
