1. In Studio 5000 Logix Designer®, create a new project using the Studio
5000 Logix Emulate controller type.
2. Configure the Studio 5000 Logix Designer project to match the
configuration of the virtual chassis. Create a Studio 5000 Logix
Emulate controller and simulated I/O to emulate the application.
3. Develop the logic for an application and configure it to run on the
emulated controller. Use symbolic tags for I/O points and alias them to
simulated I/O modules or other emulated controllers using produced
and consumed tags. Using tags in FactoryTalk View ME and
FactoryTalk View SE to simulate I/O is supported.
4. Download the program to the emulated controller and debug it using
the tools in Studio 5000 Logix Designer.
5. After verifying the program operation with the emulated controller,
save a copy of the project for reference.
