AB 1762-L24BWAR
Panel Mounting Procedure Using Modules as a TemplateThe following procedure allows you to use the assembled modules as a templatefor drilling holes in the panel. If you have sophisticated panel mounting equipment,you can use the dimensional template provided on page 6. Due to modulemounting hole tolerance, it is important to follow these procedures:1. On a clean worksurface, assemble no more than three modules.2. Using the assembled modules as a template, carefully mark the center of allmodule-ounting holes on the panel.3. Return the assembled modules to the clean work surface, including anypreviously mounted modules.4. Drill and tap the mounting holes for the recommended M4 or #8 screw.5. Place the modules back on the panel and check for proper hole alignment.6. Attach the modules to the panel using the mounting screws.
1762-L24BWAR WARRANTY 12 months
Welcome to Veronica for more info:
cell: 86 18106957056(whatsapp or skype)
veronica@nseauto.com
1762-L24BWAR
