The PLC 1768-EWEB is a CompactLogix Enhanced Web Server module. Using a 1768-EWEB module allows you to remotely monitor and modify control system data and information via XML web pages. It uses 802.3 compliant shielded or unshielded twisted pair for connection and comes in two series, A and B. Status LED displays are used in this PLC-5 equipment. It has 1 Port, 0 Motion Axes, and 1 Ethernet RJ45 Category 5 Interface. It supports up to 64 TCP/IP Connections and 128 CIP Connections. The communication rate of 1768-EWEB is 10/100 Mbps. It weighs around 7.5 ounces and comes without an enclosure. It can be panel mounted or installed onto the DIN rail.
It also has a flash file system with 2 Mb of space to store web pages and data views. This device consumes 4.34 Watts of power and has an isolation voltage of 30 Volts. The 1768-EWEB can be placed into slot 3 or slot 4 of the CompactLogix 1768 Bus. This enhancement is for use with the 1769-L45 controller.
