1769-L30 Description
The Allen-Bradley 1769-L30 compact Logix processor module can support up to 16 I/O modules with 2 expansion cables on a maximum of 3 I/O banks.
Each I/O bank requires its own power supply, and only one 1769-L30 processor module or any Logix controller module can be connected to a compactLogix system at a time. The 1769-L30 can be used anywhere in an industrial area. The 1769-L30 can communicate with any device through an RS-232 port with either a 1747-CP3 or a 1756-CP3 programming cable. It has a user memory of 256 KB and runs on RS5000 software.
The 1769-L30 has a current backplane of 800 mA at +5V DC and 0 mA at +24V DC. It has an operational temperature range between 0° to 60°C (32° to 140°F), at a 5% to 95% non-condensing relative humidity. The 1769-L30 has a key switch on the front panel for controlling the operation mode.
