The module can be mounted on a DIN rail (15 mm high) or with 4 screws. The following illustration shows the electrical connection of the input module

The digital input module 07 DI 92 is used as a remote module on the CS31 system bus. It contains 32 inputs, 24 V DC, in 4 groups with the following features

• The 4 groups of the inputs are electrically isolated from each other and from the rest of the unit.

• The module occupies two digital addresses for inputs on the CS31 system bus.

The unit works with a supply voltage of 24 V DC. The system bus connection is electrically isolated from the rest of the unit
