ABB 81AR01A-E GJR2397800R0100 Relay Output Module

81AR01A-E GJR2397800R0100 Relay Output Module

The 81AR01A-E is a Relay Output Module, manufactured and designed by ABB as part of the P14 Series used in the ABB PROCONTROL P system.

This module is mainly used for activating the triggering actuators of the protection equipment in connection with module 83SR04-E/R1411.

The module contains type-tested relays *) with positively driven contacts. This allows to perform disconnecting operations, e.g. 2-out-of-3.

Via auxiliary contacts, the position of each individual relay (function unit 1 ... 8) can be scanned.

Relay K9 is provided for overall disconnection of relays K1 through K8. It contains no position indication.

The outputs for connecting the actuators have a protective circuit (zero diode).

The supply lines for the actuators have fuses of single-pole type (R0100) and twin-pole type (R0200). Based on a certain configuration (cf. "module configuration"), the fuses can be bridged (e.g. in the case of series connection of contacts for a 2-out-of-3 concept).

Features

The module contains 8 relays (function units) which can jointly be connected or disconnected via a ninth relay.

Two versions of the module are available:

- Version R0100 for actuators to 1 voltage (positive)

-Version R0200 for actuators two 2 voltages (positive and negative)
