88FV01F GJR2332300R0200 Frequency Module
The 88FV01F Frequency Module is used to generate and receive the baseband in the range of 0.1...2 MHz needed for telegram transfer. In addition, it contains anoise receiver for the reception of event and acknowledgement annunciations in the range of 5 ...7 MHZ.
The 88FV01 module is used in the master station. A remote bus line is directly connected to it.
The 88FV01 module is available in two versions. These differ only by the fact that their noise receivers are conditioned differently.
88 FV01/R0100: for connection of remote bus lines with a length of 850 m to 1.5 km
88 FV01/R0200: for connection of remote bus lines up to amaximum length of 850 m
Features
Disturbances on the module are signalled by a light-emitting diode provided at the front.
Functional Description
The module essentially consists of the following functional sections :
-Baseband transmitter
-Transmission level monitoringfor baseband transmitter
-Baseband receiver
-Noise receiver.
The signals of the baseband transmitter and of the noise receiver are each switched to a comon repeater via an isolating transformer and a transmission/reception filter.
Technical Specifications
| Manufacturer |
ABB |
| Part Number |
88FV01F |
| Ordering Information |
GJR2332300R0200 |
| Product Catalog |
PROCONTROL System |
| Description |
Frequency Module |
| Voltage |
24 V |
| Current |
260 mA |
| Dimensions |
25.4 cm x 20.3 cm x 2 cm |
| Weight |
0.42 |
