Product Description:
The S900 components are based on a passive
backplane suitable for mounting on a DIN rail or
directly in a sub-distribution board. The passive
backplane includes internal bus communication,
terminals for field circuits, communication, and
power supply. The function modules are plugged
into the backplane in their appropriate slots. The
redundant backplane has two slots for power
supply units, two slots for communication interfaces, and 16 slots for function modules. Digital
function modules have up to 8 channels, analog
modules up to four. Therefore, when using a
redundant backplane, 128 digital or 64 analog
channels can be connected per station. In the
case of the S and B series, up to ten S900 stations
can be connected on a single fieldbus line.
