ABB CI520V1 3BSE012869R1 AF100 Communication Interface
The Advant Fieldbus 100 data base element specifies an Advant Fieldbus 100 connected to an Advant Controller 400 Series. The data base element contains diagnostic information of both the fieldbus (Advant Fieldbus 100) and the CI520V1 communication module itself.
Function:
The CI520 communication module can be connected to single or redundant media (one or two cables). The terminal CABLE_I specifies if single or redundant media is installed for the Advant Fieldbus 100. The default is single media.
The Advant Fieldbus 100 data base element can be created in the system but can not be removed. It is however possible to disable the function of the element by setting the IMPL terminal to 0. The data base element can also be reconfigured to specify a different Advant Fieldbus 100 bus if one fieldbus is removed and another is inserted in the system.
Diagnostics:
The Advant Fieldbus 100 data base element indicates diagnostics for both the CI520V1 communication module and Advant Fieldbus 100. The ERR terminal indicates fatal errors and the WARNING terminal indicates non-fatal errors. The DIAG terminal specifies a more detailed description of what causes the error or warning indication. One or more diagnostics indicators may be set. A few typical errors are listed in the following table.
Features:
Fieldbus Communication: CI520V1 supports communication via the AF100 fieldbus protocol.
Configurability: Allows for flexible configuration for different applications.
Redundancy: Designed for redundant configuration, ensuring uninterrupted operation.
Hot Swapping: Modules can be replaced during operation.
Galvanic Isolation: Provides electrical isolation between inputs and outputs.
Diagnostic Capabilities: Monitors health and status.
Technical Specifications
| Manufacturer |
ABB |
| Part Number |
CI520V1 |
| Ordering Information |
3BSE012869R1 |
| Product Catalog |
Advant Fieldbus 100 |
| Description |
AF100 Communication Interface |
| WEEE Category |
Product Not in WEEE Scope |
| Customs Tariff Number |
8517620000 |
| Dimension |
265 mm x 27 mm x 120 mm |
| Weight |
0.2 kg |
