Products Detail:
|
ABB CPU module PM904F 3BDH001002R0001
|
|
This CPU module is the high-end base unit of the Freelance AC 900F controller family. It typically supports up to 1500 I/Os. 4 Ethernet interfaces, 800 MHz CPU clock, 48 MB Controller Memory: 16 MB battery buffered SRAM, 32 MB DRAM. 4 slots for assembling Communication Interface Module.
The operating system can be loaded during software installation. Needs an external 24 V DC power supply. Software version 2019 or higher is mandatory. Display Unit TD 951F and Battery TA 951F are not included.
Features and benefits:
More connectivity with serial ports and Ethernet ports
Built-in SD card support
New Ethernet-based protocols – Modbus TCP and IEC 60870-5-104
G3 compliant as standard
Built-in power supply
Optional LCD providing enhanced security through controller lock
Optional redundancy
|
General info:
|
Aticle number
|
3BDH001002R0001
|
|
Life cycle status
|
Active
|
|
Redundancy
|
Yes
|
|
Clock Frequency
|
800 MHz
|
|
Performance, 1000 boolean operations
|
0.12 ms
|
|
Memory
|
48 MB
|
|
RAM available for application
|
16 MB
|
Detailed data
|
Processor type
|
PowerQUICC II Pro
|
|
Switch over time in red. conf.
|
500 ms
|
|
No. of tasks per controller
|
9
|
|
Power supply
|
24 V DC
|
|
Power consumption +24 V typ/max
|
24 W / 30 W
|
|
Power dissipation
|
18 W
|
|
Built-in back-up battery
|
Lithium battery (TA 951F)
|
|
Clock synchronization
|
yes
|
|
Ethernet channels
|
4
|
|
Ethernet interface
|
Ethernet (IEEE 802.3), 100/10 Mbit/s, RJ-45, female (8-pole)
|
|
RS-232C interface
|
3 (2 general, 1 for service tool)
|
