ABB DCS880/DCT880 3ADT220166R0002 SDCS-CON-H01 Excitation board
|
Part Number
|
DCS880/DCT880 3ADT220166R0002 SDCS-CON-H01
|
Weight
|
0.5
|
|
Manufacturer
|
ABB
|
Dimension
|
7.6 cm x 10.2 cm x 5.1 cm
|
|
Payment
|
T/T
|
Type
|
Excitation board
|
|
Order(MOQ)
|
1
|
Lead Time
|
IN STOCK
|
If you have any questions about DCS880/DCT880 3ADT220166R0002 SDCS-CON-H01, please contact me!
+86 189 6519 6563
sales17@amikon.cn
+86-189 6519 6563
The ABB DCS880/DCT880 3ADT220166R0002 SDCS-CON-H01 is a AC Drives module designed for use in ABB's 800xA or AC 800M control systems. It is used to interface with digital signals, providing input and output capabilities for various control applications.
1. General Description:
- **Module Type**: Digital Input/Output Module.
- **Purpose**: Interfaces with digital signals to provide control and monitoring functions in industrial automation systems.
2. Specifications:
- **Channels**: Typically, this module has 16 digital input channels and 16 digital output channels.
- **Input Type**: Digital signals, which could be normally open (NO) or normally closed (NC) contacts.
- **Output Type**: Digital outputs, which can include relay outputs or transistor outputs, depending on the specific variant.
3. Electrical Characteristics:
- **Input Voltage Range**: Typically designed to handle a range of input voltages (e.g., 24V DC).
- **Output Voltage Range**: Outputs usually operate within the same voltage range as inputs or specified by the module.
- **Current Ratings**: Each input and output channel has specific current ratings, with outputs typically capable of sourcing or sinking a certain amount of current (e.g., 0.5A to 1A per channel).
