The DI803 is an 8 channel 230 V a.c./d.c. digital input module for the S800 I/O. This module has 8 digital inputs. The a.c. input voltage range is 164 - 264 volt and the input current is 7.6 mA at 230 V a.c. The d.c. input range is 175 - 275 V and the input current is 1.6 mA at 220 V. The inputs are individually isolated. Every input channel consists of current limiting components, EMC protection components, input state indication LED and optical isolation barrier.
General info:
Article number:3BSE022362R1
Type:Digital Input
Signal specification:230 V a.c., 220 V d.c.
Number of channels:8
Signal type;Current sinking
Mechanics:S800L
Detailed data:
Input voltage range:"0"0..50 V a.c., 0..40 V d.c.
Input voltage range:"1"164..264 V a.c., 175..275 V d.c.
Input impedance：30 kΩ (a.c.) 134 kΩ (d.c.)
Isolation：Individually isolated channels
Filter times： (digital, selectable)2, 4, 8, 16 ms
Input frequencey range：47..63 Hz
Analog filter On/Off delay：5 / 28 ms
Maximum field cable length：200 meters (219 yards) 100 pF/m for a.c., 600 meters for d.c.
Rated insulation voltage：250 V
Dielectric test voltage:2000 V a.c.
Power dissipation:Typ. 2.8 W
Current consumption +5 V Modulebus:50 mA
Features and benefits:
8 channels for 230 V a.c./d.c. inputs with current sinking
Individually isolated channels
Voltage supervision of field input power
Input status indicators
Signal filtering
Process connection via detachable connectors
