Function：
The Power Link Module and the head station HS 8x0 form a Linking Device LD 800P. The Power Link Module can only be operated with the head station HS 810, HS 820 or HS 840. The Power Link Module can be mounted within
zone 2. PL 890 provides an inrinsically safe interface per IEC 61158-2. The Power Link Module supplies PROFIBUS PA devices powered by the bus.For the data transmission between Power Link Module and head station a wire link has to be made between Power Link Module terminals and head station terminals The communication is seamless. The Power Link Module does not have to be programmed. The PROFIBUS PA segment has a baud rate of 31.25 kbit/s in accordance with IEC 61158-2.
Power：
Nominal voltage: 20 ... 35 V DC
Nominal current :430 mA ... 190 mA
Safety relevant maximum voltage Um :253 V AC/ 125 V DC (Note! Um is not a rated nominal voltage)
Ripples: < 10 %
Galvanic separation
CH/PROFIBUS DP :safe galvanic isolation in accordance with EN 50020, voltage peak value is 375 V
PROFIBUS PA/Power: safe galvanic isolation in accordance with EN 50020, voltage peak value is 375 V
CH/Power:Function isolation, rated isolation voltage 50 Veff
Field bus connection
Connection: Terminals 3, 15+; 2, 14-
Profibus PA: in accordance with IEC 61158-2
Nominal voltage: 12,8 ... 13,4 V
Nominal current :< 100 mA
Terminator impedance :100 Ohm integrated
Protocol: PROFIBUS DP V1
