Features
• 1-kV Isolation (operational): 1-second test
• Continuous voltage applied across isolation barrier: 60 VDC / 42.5 VAC
• UL1950 recognized component
• EN55022 class B EMC performance
• 7-Pin PDIP and 12-pin SOP packages
• Input voltage: 5 V, 12 V, 15 V, or 24 V
• Output voltage: 3.3 V, ±5 V, 7 V, 9 V, ±12 V, or ±15V
• Device-to-device synchronization
• Thermal protection
• Short-circuit protection
• High efficiency
Applications
• Signal path isolation
• Ground loop elimination
• Data acquisition
• Industrial control and instrumentatio
Description
The HS810 series is a family of 2-W, isolated, unregulated DC/DC converter modules. Requiring a minimum of external components and including on chip device protection, the HS810 series of devices provide extra features such as output disable and synchronization of switching frequencies.
This combination of features and small size makes the HS810 series of devices suitable for a wide range of applications, and is an easy-to-use solution in applications requiring signal path isolation
