Product Description:
The DEVICE definition block supports SCSI communication with the INICI03 and
INICI13A. When a device block is configured, OPC90 will automatically detect the
currently installed SCSI bus adapter(s) and search each adapter bus for INICI03 /
INICI13A devices. Detected devices will appear in the primary and secondary port list
boxes that are part of the DEVICE block properties. They are listed as devices like
S0001:, S0002: etc. The ‘S’ indicates SCSI followed by the adapter card number,
adapter bus number, adapter logical unit number and INICI03 SCSI target ID. Note that
the target ID is the value set by switches on the Bailey INICI03 INICI13A module or
INICI13A INICT13A module. The INICI03 or INICI13A must be powered up, configured
to utilize its SCSI communication channel and attached to a PC SCSI host adapter card.
