Product Description:
Advant Controller 400 Series controllers are connected to the Advant Fieldbus 100
using the communication interface CI520, which is mounted in a submodule carrier
module in Advant Controller 450 and in the CPU in an Advant Controller 410.
CI520 must always have an external modem, either a TC625 (for coaxial media) or
a TC512/TC516 (for twisted pair). The cables that are used between CI520 and the
external modem are TK515 (AC 450/AC460) or TK593 (AC 410).
For twisted pair media, the minimum cable length between two modems
(for example, TC516 and TC513) or two communication interfaces with integrated
modems (for example, CI527 and CI869) is 4 meters (13 ft). This is true also for
redundant CI modules in a controller, for example, the cable between a redundant
pair of CI869s in an AC 800M controller also needs to be 4 meters.
