Product Description:
Speed Measurement Board YPH107A
The board can be used for accurate speed and
position measurement. Connection to the APC is
through the parallel bus. For positioning there is
a 32 bit hardware counter.
• 1 digital input for synchronisation
• 1 pulse encoder input
• 2 analogue outputs
Control voltage 24 V AC/DC or 110 V AC/DC.
synchronisation Input impedance 3 kΩ at 24 V and 13 kΩ
at 110 V. Hardware delay 1 ms or 10 ms,
software adjustable.3 opto isolated channels (A, B and Z),
differential or single ended tachometers.
± 13 mA current input or ± 24 V voltage input.
Max. input frequency 300 kHz.Output voltage ± 10 V, output current ± 10 mA.
Resolution 12 bits, accuracy ± 1 %.
