ac dc 24W power adapter 12VDC 2a with ce rohs approval
Specifications:
-
AC-DC power adapter
-
output: 12VDC, 24VDC
-
Low ripple&noise regulation
-
CE, and ROHS approval
-
1.5 years warranty
Features:
-
Universal AC input: 100~240Vac
-
Protections: Short circuit / Overload
-
No load power consumption < 0.5W /Over voltage
-
2 pins US / European/UK type plug
-
Fully enclosed plastic case
-
Class II power (without earth pin)
General Specification
-
AC inrush current (max.) ..............Cold start, <30A peak at 115VAC or <50A peak at 230VAC
-
Overload protection......................Hiccup mode, auto-recovery
-
Over voltage protection ...............Clamp by zener diode > 120%
-
Withstand voltage.........................I/P-O/P: 3KVAC, 1minute
-
Working temperature ................. -10°C~50°C @ 100% load, 50°C @ 70%
-
Safety standards........................ . EN61347-1-2,, CSA 22.2, TUV EN60950-1
-
EMC standards.......................... .. EN55022-B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,11
-
Length of output cable ............ ....180cm of 18AWG or 120cm length
-
Standard DC plug....................... ..P1J: 2.1øx5.5øx10mm or 2.5øx5.5øx10mm / -C+, turning fork type
-
Male or USB DC connector
Product certificates:
ce rohs approval ac dc 24W power adapter 12V DC 2a / 24vDC 1a
