1.Automatic adding water function, and automatic filling water upon the water short storage while testing.
2.Autotatic operation to test process finished, easy to use.
3.Temperature control: LED digital temperature controller can make accurate testing of temperature setting, control and display.
4. LED digital timer, when the inner box's temperature reached the setting value, then start to time to ensure the test complete.
5.Accurate pressure: temperature chart always shows the inner box's pressure and relative humidity.
6.Water device is automatically discharge not saturated steam in order to achieve the best steam quality.
7.A integrated silica gel door gasket, air tightness is very good, and long operation life.
8.The inner box is mirror-polished , graceful and non-pollution
|
Model
|
OLT-TS-25
|
OLT-TS-35
|
OLT-TS-45
|
|
Internal Dimension ΦxD (mm)
|
300x250
|
350x450
|
450x550
|
|
External Dimension ΦxD (mm)
|
850x1300x900
|
900x1350x900
|
1000x1480x1000
|
|
Steam Temperature Range
|
Steam Temperature Range: 100℃~135℃, (143℃ is optional)
|
|
Relative Pressure/ Absolute Pressure
|
Relative pressure: display values indicated on the pressure gauge
Absolute pressure: pressure gauge value adds 100 Kpa (The actual value in the inner box)
|
|
Steam Humidity
|
70~100％R.H. steam humidity adjustable
|
|
Steam Pressure (Absolute Pressure)
|
101.3Kpa +0.0Kg/cm2 ~ 2.0Kg/cm2 ; (3.0Kg/cm2 is special standard)
|
|
Recursive Device
|
Steam in forced-circulation
|
Accelerated Aging Test Pressure Cooker Safety Device
1. Safety device for the pot: If the inner box is not closed , the machine can not start
2. Safety Valve: When the inner box’s pressure higher than the machine’s undertake value, it will self-relieve.
3. Double overheat protection device: When inner box’s temperature is too high, it will alarm, and Automatic cut off the heating power.
4. Cover protection: The inner box’s cover is made of aluminum alloy, can protect the worker from scald.
Packaging:
-The glass parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent.
|
Shipping method
|
Note
|
|
Express
|
Door to door, very convenient, don't need to clearance or pick-up
|
|
By air
|
Airport to airport, you need to do the customs clearance and pick up the
goods at your local airport, which you can have a local shipping agent to do for you.
|
|
By sea
|
Port to port and you need to do the customs clearance and pick-up the goods
at your local port, which you can have a local shipping agent to do for you.
|
