advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
|
|
|
|
|
|
|
|
|
mechanical power-off auto open gate
|
|
|
|
|
|
|
Advanced & Intelligent Metro Turnstile Core Technology
Strong mechanism structure
The lossless modular mechanism structure independently developed by CMOLO, combined with the optimized mechanical structure design, enables the mechanism to have high anti-fatigue performance and impact resistance; the full CNC processing technology ensure the precision, strength, concentricity of the mechanism, and the transmission ratio are accurate, efficient and stable, which can precisely control the rotation angle of the gate, reduce the loss to ensure the reliability of the mechanism, and enhance the service life of the mechanism and ensure that the subway speed gate turnstile is stably working in the high pedestrian flow rate, and the normal operation of the speed gate turnstile for a long time.
Advanced core logic algorithm
The subway speed gate turnstile adopts advanced servo control system and DSP+ARM motor control technology, combined with CMOLO's originally developed motor control algorithm, to achieve precise control and positioning of the obstacle and maintain stable performance.
The turnstile adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, the turnstile can sensitively detect illegal intrusions such as reverse passing and tailgating, and can issue warnings in the form of sound and light, and can be linked with other security systems.
Long service life
The mechanism and control system of the subway speed gate turnstile have passed 10 million times life tests.
All-around Pedestrian Safety Protection
Automatic door opening when mechanical power failure
The subway speed gate turnstile has the automatic opening technology when there is mechanical power failure. After the power failure, the gate can be opened automatically, which is convenient for the rapid evacuation of the crowd; compared with the conventional power failure opening method, it is safer and more reliable.
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, speed gate turnstile can protect pedestrian safety more comprehensively.
Over-force feedback control
When the gate is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.
Emergency open
The subway speed gate turnstile equips with emergency escape control device, to make the system automatically open the gate to evacuate pedestrian.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Seamlessly compatible with ticket checking system
The subway speed gate turnstile has very strong compatibility and can be seamlessly connected with the ticket checking system to complete the smooth ticket checking movement.
Modular Design
The subway speed gate turnstile adopts a modular design and adopts the CANBUS technology commonly used in high-end industries. Each functional module is independently mounted on the Bus, and the daily inspection and maintenance are convenient and fast.
Customization
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
| Lane width |
The maximum lane width of turnstile is 900mm, and the cabinet length can be increased accordingly |
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
