AIE7 Power Entry Module IEC Filter with Switch
IEC EMI filters with switch, it has compact unit, light weight, low price. Rear/front or snap-in mounting.(S and S1 type). Optional medical versions (B type) comply with the requirements of IEC/EN 60601-1. Test Voltage ( 1min ): Line to Ground: 2000AC. Line to Line:1450VAC.
The MCTAIE7 power entry module combines an IEC inlet, mains filter with excellent filter attenuation and a mains switch in a small form factor. It has high saturation resistance and excellent thermal behavior. Welcome customized products.
Quick Details
Part No: Filter With Switch |
Brand name: MCT |
Rated Voltage: 120/250VAC |
Custom made: Available |
Rated Current: 1A~10A |
Logo: Can be customized |
Operating Frequency: 50/60Hz |
Packing: Carton, can custom |
Temperature range : HPF 25/085/21 |
Shipping: Air, Ship, etc |
Lead time: 25 days after payment |
MOQ: Any quantity |
Certification: ISO9001,ROHS,CE |
OEM: Available |
Part Information
Product Name: AIE7 Power Entry Module IEC Filter with Switch
Applications: Single phase power supplies, switch-mode power supplies. Small to medium-sized machines and household equipment. Portable electrical and electronic equipment. Test and measurement equipment. Medical equipment.
Packing details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
