Airflow jet mill pulverizer machine
Higao Tech produce good quality airflow jet mill pulverizer machine in china. Micronizer jet mill is used to make micron grade powder in refined chemicals, pharmaceuticals, plastics, aerospace and many other industries for a special application.
1. Introduction:
Fluidized bed airflow jet mill pulverizer machine is the latest super-fine airflow grinding machine.
Combines the multifold nozzle tube technology, fluidized-bed technology and horizontal classifying technology, jet mill has realized the integrated technology system containing multiple flow field, fluidized material layer, horizontal grading and mechanical-electrical integration.
The super fine powder made by air jet mill are agricultural chemicals, carbon black, ceramics, resins, pharmaceuticals, cosmetics, pigment and dyestuff, toner, metallurgy, precious metals, mine, energy, Titanium Dioxide, electronics, medicines, pesticide, Propellants, activator, plastic, paper-making, painting, grinding-stuff, food, high-pure product, polymer material, advanced electromagnetic material, magnetic material, semiconductor material, fine chemical powder, reagent, etc.
2. Working Principle:
Fluidized bed airflow jet mill pulverizer machine consists of air supply unit, feeding unit, grinding unit, powder grading unit and powder collecting unit.
The fresh compressed air from the air supply unit mixing with the particles from the feeding unit in the grinding chamber forms the air-solid-phase flow.
The supersonic airflow generated by the ejector makes the particles collide and crush into each other. Then those particles having reached the required fineness are released by the grading unit on the top of the machine and are collected and packed by the powder collecting unit.
3. Features:
High-speed flow rate, high grinding efficiency, low energy consumption, few material wastage.
Easy to adjust the fineness of the powder. Stable and reliable.
Capable of grinding materials of great hardness.
Easy operation, fully sealed chamber, wide application (can be used to grinding heat-sensitive materials).
