Allen-Bradley 1336S-B010-AN-EN Ser: D AC DRIVE 380-480V IN STOCK

Contact: Miya

Job Title: Sales Manager

Skype: live:miyazheng520

Email: sales@amikon.cn

Tel: 86-18020776792(Whats App )

QQ :2851195450

Brand Name                 AB

Product reference       1336S-B010-AN-EN

The Allen-Bradley 1336S-B010-AN-EN3 Plus Adjustable Frequency AC Drive is part of the 1336 Plus drive family which provides microprocessor control for 3-phase induction motors in applications with the need for exceptional torque control. Like every drive in 1336 plus product line, it has digital setup and controls which ensures precise and repeated operations, and it is designed with in-built protection features to ensure smooth operation. It has an operating AC voltage range of 380 to 480 Volts AC at 50 to 60 Hertz, with an input tolerance of -/+10% at 47 to 63 Hertz, and it has a displacement power factor of 0.95. The 1336S-B010-AN-EN3 has a drive efficiency of 97.5%, and it has a short-circuit rating of 200,000 Amps. It has a variable torque input rating of 14 to 18KVA at 22 Amps, and an output rating of 17KVA at 21 Amps, and it is designed to produce full voltage ratings on all 3-phases. It provides AC overvoltage and under voltage trips and provides microprocessor-controlled over temperature trips at the heatsink. It provides a transient line protection of up to 6000 Volts with phase-to-phase protection at the output using a MOV (Metal Oxide Varistor), and it is fully capable to ride through time 15 milliseconds of power loss at a full load.

The 1336S-B010-AN-EN3 uses the sensorless vector control the standard volt per hertz control (V/Hz) for motor control, and it uses a sine coded pulse modulated (PWM) control signal with a programmable frequency (carrier) range of 2 to 10 KHz for control. It has a programmable output frequency range of 0 to 400 Hertz, with an output voltage range, selectable between 0 and the rated voltage, and it has an input control accuracy within ±0.01%, and ±0.4% of the maximum output frequency. The 1336S-B010-AN-EN3 has independent acceleration and deceleration times that are programmable from 0 to 3,600 seconds with 0.1-second increments, and it has an overload capability of 115% of the rated output for 60 seconds and 150% of the rated output for 3 seconds. It provides Class 10 motor overload protection with a sensitive response, and it has a software-controlled current limit range, adjustable from 20% to 160%. The 1336S-B010-AN-EN3 has a functional temperature range of 32 to 122 degrees Fahrenheit at 5 to 95% relative humidity, and it has storage limits of –40 to 158 degrees Fahrenheit. It has NEMA Open Type rated enclosure, and it is designed to operate at a height of 1000 meters without de-rating. It weighs about 15.90 kilograms, with net dimensions of 260.0 x 350.0 x 212.0 millimeters, and it is CE, UL, and CSA certified.
