Product Details:
- Rated short-circuit breaking capacity lcu at 400 V, AC:100 kA
- Rated operation power at AC-3, 400 V:7.5 kW
- Rated permanent current Iu: 16 A
- Rated operation power at AC-3, 230 V: 4 kW
- Rated operating voltage :230 A
- Type of control element: Turn button
- Overload release current setting: 10 A
- Type of electrical connection of main circuit: Screw connection
- Rated frequency: 60 Hz
- Magnetic release current per IEC: 208 A
- Rated operational current (Ie) per IEC:16 A
- Magnetic trip current: 208 A
- Rated supply current (Ie): 1.6 A
- Total power loss (Pv) for circuit breaker at rated load operating temperature: 6 W
- Current range: 10 to 16 A
- Ultimate short circuit breaking capacity (Icu) per IEC: 6 kA @ 690V
- Rated service short circuit breaking capacity (Ics) per IEC: 50 kA @ 500V
- Hp rating, max: 5 Hp @ 230V, 3-phase
- Rated insulation voltage (Ui): 690V per IEC, SEV, VDE0660
- Electrical life cycle: 100000 operations (Ie maximum)
- Switching of standard motors per IEC: 7.5 kW @ 400/415V (AC-3), 3-phase
- KW rating, max: 7.5 kW @ 415V (AC-3), 3-phase
- Short circuit current (Type 2 coordination), max: 65 kA @ 480V
Perfect Service
· Order now for immediate delivery via DHL, UPS, Fedex, TNT;
· Payment: 100% T/T on stock items before shipment.
· Warranty: 12 months warranty on new parts;
· Service: 24/7 online service;
· Limited time good prices, free online quotes, huge discounts.
About FAQ
Q1: How long is your delivery time?
A1: If the goods are in stock, it usually takes 2-3 working days. If the quantity is large, it takes 5-7 business days after payment is received.
Q2: What about your shipping package?
A2: Most of our products are shipped in original new packaging and we will cover our professional protective foam packaging ensures damage free shipping worldwide .
