Brand Name AB
Product reference 1746-OG16
The Allen-Bradley 1746-OG16 is a SLC 500 Digital DC Output Module. This Digital DC Output Module has a Voltage Range of 5 Volts DC Sink and 16 Outputs. It has a Backplane Current (5 Volts) of 180 milliamps.
The Allen-Bradley 1746-OG16 has voltage category of 5V DC TTL signal input (sinking). This module has 16 outputs and it has 16 points per common. The operating voltage of the 1746-OG16 is 4.5-5.5V DC with a maximum 50 mV peak-to-peak ripple. The 1746-OG16’s backplane current at 5V is 0.18A and the backplane current at 24V is 0A. The Off-state voltage of this module is from 4.5-5.5 V DC. The maximum Off-state leakage current of this module is 0.1 mA. The continuous current per point is 24 mA. The 1746-OG16’s operating temperature is from -13-140 °F while the nonoperating temperature is from -40-185 °F at 5-95% relative humidity without condensation. The operating vibration of this module is 2g at 10-500 Hz and 2.5 g at 57-2000 Hz while the operating shock is 30g.
The Allen-Bradley 1746-OG16 is intended for industrial environments with a pollution level no higher than Pollution 2 (as defined in EN / IEC0664-1). The enclosure should be accessible only by the included appliance. Do not disconnect equipment unless power has been removed and if the area is known to be dangerous because an electric arc will be created.
