Allen-Bradley 1756-IV32 Input Module

Module NO:1756-IV32

Brand:Allen-Bradley

Condition:New

Warranty:12 months

Regarding product price: Affected by market fluctuations, please contact us to confirm the price of the final transaction before placing an order



Allen-Bradley 1756-IV32

       Product Details:

  • The Allen-Bradley 1756-IV32 is a digital input module having 32 inputs with 16 points per group. The 1756-IV32 module is compatible with the ControlLogix 1756 chassis but before you can connect the module to the chassis, you will need an RTB, or removable terminal housing, for the module.
  • For the 1756-IV32 module, you can only use the 1756-TBCH or 1756-TBS6H RTB. The 1756-IV32 has an operating voltage range of 10 to 30 Volts DC and is a 12/24 Volts DC source module. The current draw of this module is 120 milliamps at 5.1 Volts and 2 milliamps at 24 Volts. It has a total backplane power of 0.66 Watts and a nominal input voltage of 24 Volts DC.
  • The module also has a continuous voltage of 250 Volts. The maximum power dissipation of the 1756-IV32 module is 4.1 Watts at 60 Degrees Celsius, while its thermal dissipation is 14 BTU/hour also at 60 Degrees Celsius. It has a maximum inrush current of 250 milliamps, decaying to <37% in 22 milliseconds, without activation, and a maximum input impedance of 8.6 kΩ at 30 Volts DC.





    Perfect Service

  • Order now for immediate delivery via DHL, UPS, Fedex, TNT;
  • Payment: 100% T/T on stock items before shipment.
  • Warranty: 12 months warranty on new parts;
  • Service: 24/7 online service;
  • Limited time good prices, free online quotes, huge discounts.



      Our Strengths

  • Over 10 years of experience in the industry. Large inventory system, strict quality inspection before shipment
  • Short delivery time. Good price
  • Professional and honest, complete accessories
  • On Time Delivery
  • One-stop Supplier
  • Good After Service
  • Fast Shipping
  • Great Selection
  • Strict Quality Control

Product Tags 1756-IV32          1756-IV32 Input Module          1756-IV32 Allen-Bradley          ControlLogix 16 Point D/O Module
